Default DIY: 3.5mm stereo to Bose System

Alright so I bought the Audiolink for my iPhone 3G and it was working fine until after a week, it stopped charging so I returned it. I was going to get the DICE but then I found a way to make the same thing with just ~$20 and here is how:

First you need to go to RadioShack and buy a 3.5mm stereo connector. Looks like this:


Part number and Description on the RadioShack bag: 3-Conductor Stereo 1/8" 3.5mm Phone Jack PN:274-0249

You also need a soldering gun, flux, soldering wire, also i used those OOOOOOOLD audio cables that hook up to CD roms that nobody uses anymore, they fit perfect and the connectors are perfect size. Get a couple of them
Also a Drill to drill the hole and very useful in my case a Dremmel (you'll see why later)

So Remove the stereo (go here to learn how to do it How to change HVAC lights)

Now, you can use any color wire you want, as you will see later I used red twice because I didn't have any other color..., Here is where your CD-rom audio cable comes in handy:

Look at the back of the stereo, you will see the connector for the aux port used by Sirius, Dice, Audiolink. **BTW you cannot do this if you have sirius or XM installed**

You will see the pins are numbered.


What you need to do is hook up pins 1 and 13 to each other. 1 is Ground and 13 is the AUX pin. It enables the MEDIA button on the stereo.
On the 1 and 13 connector. I used a D-SUB connector from radioshack, it comes with the connector and the pins, just use the pins, you have to crimp them, use a pair of pliers.

3 goes to the R on the 3.5 connector, 5 goes to the L pin and 7 goes to the Signal Pin. It's labeled on the first pic.

so it looks like this:


That's 1 and 13, then using the CD Audio cable plug it to 3,5 and 7.

I took the pic before I move the pins to get them together btw. so put them together on one side and plug it in. Since 9 is not used it takes the empty socket on the CD Audio connector.

On the other side of that connector, use a soldering gun and solder the ends with the respective wires.


Then what I did is I wanted to place it somewhere so i picked a hole next to the cigarette plug. I used a 1/4 drill bit and drilled away. Now here is where the dremmel comes in handy:


As you can see I had to shave some of it down because the plug would not go all the way, just shave it enough so you can screw it on the other side with the ring that comes with it.

Once it's in place it looks like this:



At this point wait until you plug the stereo side, just plug 1 and 13 and then once everything is in the car route the wire from the 3.5mm socket to the back of the stereo and then plug it in. **NOTE: you may need to extend the wire. Mine was juuuuuuust long enough so if you have 2 CD Audio cables you can cut part of the other one and mate them so it's longer**

Once it's connected test it before you put everything together. turn the Radio ON then press MEDIA. AUX should come up on the screen, then plug the 3.5mm cable to the socket and the other side to your media player (MP3, iPod,, iPhone, Zune etc) and you should be able to hear it!

Enjoy!
__________________
SELLING EVERYTHING! HERE
chisss is offline   Reply With Quote Quick reply to this message
The Following 23 Users Say Thank You to chisss For This Useful Post:
12ballaholic (07-29-2013), 808MS6 (08-19-2010), AjKju (09-13-2013), balward (07-30-2013), cfdp (05-24-2010), darth wonk (03-14-2014), dynamho (05-12-2011), e4w (05-14-2012), friedricebob (03-06-2011), Halkenguard (08-27-2013), hariskt (09-05-2011), javipsijas (08-30-2010), kshiddy (03-28-2012), Mr. A. Knife (09-15-2013), Mr.Smoke (12-26-2011), nevinsrt (12-23-2011), pennskee89 (07-01-2012), Powerflow6 (02-26-2014), thor312 (07-04-2011), TurboGTU (03-11-2012), twinturbo6 (10-04-2010), Twisterad3 (05-14-2010), Viking_Quest (04-29-2010)
Sponsored Links
Advertisement

Old 04-04-2009, 05:40 PM   #2 (permalink)
Registered User

Road Rage's Avatar

Join Date: Oct 2006
Location: Mn
Posts: 2,059
Mentioned: 1 Post(s)
Tagged: 0 Thread(s)
Quoted: 4 Post(s)
Thanks: 93
Thanked 101 Times in 69 Posts
Groans: 4
Groaned at 0 Times in 0 Posts
iTrader: 0 reviews
Default

you are my new hero!

thanks for the write up, i now have some work to do
__________________

"When you can leave black marks from the exit of every turn to the braking points of the next turn, then you have enough horsepower."
"Oversteer is when you hit the wall with the back of the car. Understeer is when you hit the wall with the front of the car. Horsepower is how fast you hit the wall. Torque is how far the wall moves after you hit it."

06 Black Cherry Mica Speed6
Road Rage is offline   Reply With Quote Quick reply to this message
Old 04-04-2009, 05:50 PM   #3 (permalink)
Registered User

chisss's Avatar

Join Date: Nov 2007
Location: Terryville, CT
Posts: 748
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Thanks: 0
Thanked 29 Times in 2 Posts
Groans: 0
Groaned at 0 Times in 0 Posts
iTrader: 0 reviews
Send a message via AIM to chisss Send a message via MSN to chisss
Default

hahaha, thanks! it really is piece of cake... and cheap!
__________________
SELLING EVERYTHING! HERE
chisss is offline   Reply With Quote Quick reply to this message
Old 04-04-2009, 06:06 PM   #4 (permalink)
Registered User

tmtbiker's Avatar

Join Date: Feb 2008
Location: Melbourne, FL
Posts: 457
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Thanks: 2
Thanked 1 Time in 1 Post
Groans: 0
Groaned at 0 Times in 0 Posts
iTrader: 0 reviews
Default

thank you. bookmarked for a rainy day project! any idea where you can get those "CD Rom audio cables"? I haz none.
__________________
'06 Black Mica GT

Warranty long gone, so.. CPE CAI, Speedie6 TIP, HKS valve, TWM stage 1 SS, SPC Ball Joints, SU RMM, Vent Pod w/ VEI Boost, Shark Fin Antenna, 808Speed6's Preamp/EQ, Clutch Start Bypass, Audio Aux In Jack
tmtbiker is offline   Reply With Quote Quick reply to this message
Old 04-04-2009, 06:21 PM   #5 (permalink)
Registered User

SneakyP86's Avatar

Join Date: Apr 2008
Location: Atlanta,Ga.
Posts: 729
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Thanks: 1
Thanked 8 Times in 6 Posts
Groans: 0
Groaned at 0 Times in 0 Posts
iTrader: 0 reviews
Send a message via AIM to SneakyP86 Send a message via Yahoo to SneakyP86
Default

What is that connector you had on the wire going from 1 to 13? Also if I cant find any of the old CD audio connectors any idea of where I might can find one? Or could I just use three more connectors like you used in 1 to 13 and plug them in that way?
SneakyP86 is offline   Reply With Quote Quick reply to this message
Old 04-04-2009, 06:37 PM   #6 (permalink)
Learners License

Join Date: Dec 2005
Location: North Hollywood
Posts: 47
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Thanks: 0
Thanked 0 Times in 0 Posts
Groans: 0
Groaned at 0 Times in 0 Posts
iTrader: 0 reviews
Send a message via AIM to MZ62005 Send a message via Yahoo to MZ62005
Default

just go frys' electronics or something like best buy you'll be good
__________________
MZ6 '05 S Black and Red custom Leather, Bose w/ Moonroof, OOrah, SEMPER FI!!
MZ62005 is offline   Reply With Quote Quick reply to this message
Old 04-04-2009, 06:48 PM   #7 (permalink)
Registered User

chisss's Avatar

Join Date: Nov 2007
Location: Terryville, CT
Posts: 748
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Thanks: 0
Thanked 29 Times in 2 Posts
Groans: 0
Groaned at 0 Times in 0 Posts
iTrader: 0 reviews
Send a message via AIM to chisss Send a message via MSN to chisss
Default

Oh yea, i'll update on the 1 and 13 connector. I used a D-SUB connector from radioshack, it comes with the connector and the pins, just use the pins, you have to crimp them, use a pair of pliers. And yes, BB might have them, or a computer shop, they usually come with Optical drives (yes they still come...)
__________________
SELLING EVERYTHING! HERE
chisss is offline   Reply With Quote Quick reply to this message
Old 04-04-2009, 07:02 PM   #8 (permalink)
Registered User

monkgj's Avatar

Join Date: Mar 2008
Location: North Wales, Pa
Posts: 174
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Thanks: 0
Thanked 3 Times in 3 Posts
Groans: 0
Groaned at 0 Times in 0 Posts
iTrader: 1 reviews
Default

Awesome write up. I'll have to do this... one day...
monkgj is offline   Reply With Quote Quick reply to this message
Old 04-04-2009, 07:04 PM   #9 (permalink)
Learners License

Join Date: Dec 2005
Location: North Hollywood
Posts: 47
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Thanks: 0
Thanked 0 Times in 0 Posts
Groans: 0
Groaned at 0 Times in 0 Posts
iTrader: 0 reviews
Send a message via AIM to MZ62005 Send a message via Yahoo to MZ62005
Default

question: would you lose some sort of sound quality since the 3.5 jack on your ipod is built to output for a 2 speaker headset anyway...so wouldnt it realy be better for the audiolink version since it ouputs trhough the usb connection in the bottom so itw ould be raw in a sense?
__________________
MZ6 '05 S Black and Red custom Leather, Bose w/ Moonroof, OOrah, SEMPER FI!!
MZ62005 is offline   Reply With Quote Quick reply to this message
Old 04-04-2009, 09:14 PM   #10 (permalink)
Registered User

chisss's Avatar

Join Date: Nov 2007
Location: Terryville, CT
Posts: 748
Mentioned: 0 Post(s)
Tagged: 0 Thread(s)
Quoted: 0 Post(s)
Thanks: 0
Thanked 29 Times in 2 Posts
Groans: 0
Groaned at 0 Times in 0 Posts
iTrader: 0 reviews
Send a message via AIM to chisss Send a message via MSN to chisss
Default

I would image you would lose some quality but I can't tell a difference to tell you the truth... Songs are not in surround sound, they are stereo and you are getting stereo sound through the 3.5mm plug.

Again, i can't tell a difference, or a difference that would make me want to spend extra $100
